SONUS_FABER · 商品資訊1 / 4
點擊下方縮圖查看產品相關圖片：
SONUS_FABER音響
Sonus faber Suprema 音響
Sonus faber Suprema 音響 · Suprema · 請洽 LINE 詢價
門市預約試聽
獨立聲學視聽室實機開聲
原廠公司貨保固
台灣授權代理安心售後
自營工班調校
全台音響劇院專業施工
專人一對一解說
客製化劇院系統搭配建議
門市諮詢價
請洽 LINE 詢價
供貨狀況請洽詢
一對一門市專人諮詢週一至六 10:00-21:00
詢價型號與商品識別碼
SONUS_FABER Suprema https://maxaudio1689.com/shop/audio/sonus-faber-suprema-6bf8b6507739
產品規格
儀器級規格與硬體參數共 12 項標示
- 系統
- MAIN COLUMN: 4.5 way sealed box；SUBWOOFER: Sealed box loading, passive subwoofer；CROSSOVER: Full Discrete -Pure Analog Stereo/Mono active Crossover
- 分頻點
- MAIN COLUMN:；Front emission: 360, 430, 1700, 6700 Hz；Back emission: 500, 2300 Hz
- 頻率響應
- MAIN COLUMN:；Front emission: 45 Hz - 40000 Hz；Back emission: 500 Hz - 20000 Hz；SUBWOOFER:；16 Hz - 30/80 Hz, variable based on the setting of the electronic crossover；CROSSOVER:；MAIN: 25 Hz - 150000 Hz；PROC: 5 Hz - 150000 Hz
- 靈敏度
- MAIN COLUMN: 91 dB SPL (2.83V/1 m)；SUBWOOFER: 92 dB SPL (2.83V/1 m)
- 額定阻抗
- MAIN COLUMN: 4 Ohm；SUBWOOFER: 4 Ohm
- 擴大機
- MAIN COLUMN: 100W - 700W, undistorted signal；SUBWOOFER: 500W - 2000W, undistorted signal
- 輸入
- CROSSOVER:；OUTPUT DRIVING CAPABILITY:；Unbalanced: 6 V rms (+15,5 dBv) @ 490 Ohm；Balanced: 11 V rms (+20 dBv) @ 980 Ohm
- Connectivity
- MAIN COLUMN:；4 connectors binding post: Mid-Hi, Low.；SUBWOOFER:；2 connectors binding post；CROSSOVER:；INPUT CHANNELS: 4 Unbalanced, 4 Balanced；OUTPUT CHANNELS: 6 Unbalanced, 6 Balanced
- 產品尺寸(高x寬x深)
- MAIN COLUMN:；1905 x 650 x 880 mm / each；75 x 25.6 x 34.7 in / each；SUBWOOFER:；1451 x 850 x 595 mm / each；57.1 x 33.5 x 23.4 in / each；CROSSOVER:；110 x 451 x 424 mm / unit；4.3 x 17.8 x 17 in / unit
- 含包裝尺寸(高x寬x深)
- MAIN COLUMN:；2110 x 830 x 1200 mm / each；83 x 32.7x 47.2 in / each；SUBWOOFER (WITH OR WITHOUT CROSSOVER):；1900 x 1000 x 830 mm / each；74.8 x 39.4 x 32.7 in / each
- 重量
- MAIN COLUMN:； 110 kg / each；242,5 lb / each；SUBWOOFER:；105 kg / each；231.5 lb / each；CROSSOVER:；17 kg / unit；37,5 lb / unit
- 箱體
- Double curvature - Lute shapeHigh gloss woodCarbon fiberBlack leatherAluminum
資料來源
商品資料依下列來源與本機驗證資料整理；價格與供應狀況仍以門市洽詢結果為準。
- 主資料來源
核對日期：
