NAD
NAD PP 2e 前級擴大機
NAD PP 2e 前級擴大機 · PP 2e · 請洽 LINE 詢價
請洽 LINE 詢價
供貨狀況請洽詢
詢價型號
NAD PP 2e https://maxaudio1689.com/shop/audio/nad-pp-2e-phono-preamplifier-fddcb401d42c
產品規格
- Input Impedance (R and C)
- 100 Ohm + 180pF
- Gain at 1kHz
- 60dB
- Input Sensitivity (ref. 200mV output)
- 0.3mV
- Signal to Noise Ratio
- 78dB (A weighted, with cartridge connected)
- Input Overload (20Hz/1kHz/20kHz)
- 0.8/9/84mV
- RIAA Response Accuracy
- ±0.3dB
- Input sensitivity (ref. 200mV output)
- 2.5mV
- Input overload (20Hz/1kHz/20kHz)
- 10/102/950mV
- RIAA response accuracy
- ±0.3dB
- Output Impedance
- 100 Ohm
- Maximum Output Level
- 5.3V
- AC Supply
- External 23.5V DC
- Dimensions excl. Power supply (W x H x D)
- 135 x 49 x 72mm 5 5/16 x 1 15/16 x 2 7/8"
資料來源
商品資料依下列來源與本機驗證資料整理；價格與供應狀況仍以門市洽詢結果為準。
