NAD M33 DAC

產品規格

Input sensitivity

865 mV (ref. 200W 8 ohms, Volume maximum)

Signal to Noise ratio

>98 dB (A-weighted, ref. 1 W out in 8 ohms) >120 dB (A-weighted, ref. 200 W out in 8 ohms)

Clipping power

>210 W (0.1 % THD 1 kHz 8 ohms)

IHF dynamic power

8 ohms: 260 W 4 ohms: 520 W

Peak output current

≥25 A (in 1 ohm, 1 ms)

Damping factor

>800 (ref. 8 ohms, 20 Hz to 6.5 kHz)

Frequency response

±0.2 dB (20 Hz -20 kHz) -3 dB at 60 kHz

Input Impedance (r and c)

47kΩ/180pF

Input Sensitivity

280mV (ref. 500mV out, Volume Maximum)

Maximum input level 20Hz 20Khz

2 Vrms/8 Vrms (low sensitivity mode)

Tone Controls

Treble: ±6 dB at 10kHz Bass: ±6 dB at 100Hz

Max Output Signal

4Vrms (ref. 0.1% THD)

Maximum output level

3.9 Vrms (ref. 0.1% THD)

Output impedance

100 ohms

Input impedance (R and C)

MM: 56 kohms/100 pF MC: 100 ohms/280 pF

Signal to noise ratio (ref. 2 V Preout A weighted)

MM: >92 dB MC: >76 dB

THD+N (ref 2V Preout 1kHz)

MM:

RIAA response accuracy MM/MC

±0.2 dB 20 Hz -20 kHz

Output Impedance

2.2ohms

Output power

>100 mW/32 ohms

Supported audio file format*

MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS

Supported high resolution audio file format*

FLAC, MQA, WAV, AIFF

Sampling rate

up to 192 kHz

Bit depths

16 - 24

Network connectivity

Gigabit Ethernet RJ45 Wi-Fi 5

Supported network file share protocol

Server Message Block (SMB)

USB

1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals

Bluetooth quality

Support for aptX® HD

Bluetooth connectivity

Two-Way (Receive and Headphone modes)

Supported operating system**

Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions**

Mobile Application

Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops

Front panel

7-inch full colour touch screen

Remote control

HTRM 2 remote control

Dimensions WxHxD **

435 x 133 x 396 mm (17 1/8 x 5 1/4 x 15 5/8 ”)

Net Weight

9.7kg (21.4lb)

Shipping Weight

18.4kg (40.6 lb)

Shipping Size (W x H x D)

569 x 258 x 519 mm (22 13/32 x 20 7/16 x 10 5/32 ”)
