NAD
NAD M22 V2 後級擴大機
NAD M22 V2 後級擴大機 · M22 V2 · 請洽 LINE 詢價
請洽 LINE 詢價
供貨狀況請洽詢
詢價型號
NAD M22 V2 https://maxaudio1689.com/shop/audio/nad-m22-v2-stereo-power-amplifier-36bd28a9aa2c
產品規格
- Continuous output power into 8 ohms and 4 ohms (Stereo mode)
- 300 W (20 Hz-20 kHz at 0.1% THD, both channels driven)
- Signal to Noise Ratio
- >100 dB (A-weighted, ref. 1 W in 8 ohms
- Clipping power (Stereo mode, at 1 kHz 8 ohms 0.1 % THD)
- >300 W
- Clipping power (Bridge mode, at 1 kHz 8 ohms 0.1 % THD)
- >950 W
- IHF dynamic power (Stereo mode, at 1 kHz 1 % THD)
- 8 ohms: 400 W
- Damping factor
- >800 (ref. 8 ohms)
- Frequency response
- ±0.1 dB (20 Hz - 20 kHz)
- Input sensitivity (for 300W in 8 ohms)
- 1.73 V
- Gain level
- Low: 19 dB
- Minimum input level for Auto Trigger
- 5 mV at 1 kHz
- Gross dimensions (W x H x D)
- 435 x 103 x 379 mm
- Net Weight
- 8.9 kg (19.6 lbs)
- Shipping Weight
- 15 kg (33.1 lbs)
資料來源
商品資料依下列來源與本機驗證資料整理；價格與供應狀況仍以門市洽詢結果為準。
