NAD
NAD M17 V2i 前級擴大機
NAD M17 V2i 前級擴大機 · M17 V2i · 請洽 LINE 詢價
請洽 LINE 詢價
供貨狀況請洽詢
詢價型號
NAD M17 V2i https://maxaudio1689.com/shop/audio/nad-m17-v2i-surround-sound-preamp-processor-8513348f0de5
產品規格
- HDMI
- Up to 4K UHD
- Coaxial
- 0.5 Vpp
- Ethernet
- RJ45 10/100/1000 Ethernet
- Input Impedance (R and C)
- 56kΩ + 220pF
- Input Sensitivity
- 40mV (ref. 500mV out)
- Maximum Input Signal
- >8Vrms
- Signal/Noise Ratio, A weighted
- >90dB (ref. 500mV in, 500mV out, volume set to unity gain)
- Channel Separation
- >70dB (ref. 1kHz / 10kHz)
- Frequency Response
- ±0.3dB (ref. 20Hz - 20kHz, Tone Active)
- Frequency Response (subwoofer out)
- 10 - 200Hz (ref. -3dB)
- Maximum output level
- >8 Vrms into 600 Ω
- Treble
- ±10dB at 10kHz (ref. 2V in, 2V out)
- Bass
- ±10dB at 100Hz (ref. 2V in, 2V out)
- Unit Dimension (WxHxD) Gross*
- 435 x 156 x 386mm
- Net Weight
- 10.9kg (24lb)
- Shipping Weight
- 17.5kg (38.6lb)
資料來源
商品資料依下列來源與本機驗證資料整理；價格與供應狀況仍以門市洽詢結果為準。
