NAD C 700 網路串流機

產品規格

Continuous output power into 8 ohms and 4 ohms

>80 W (ref. 20 Hz-20 kHz at rated THD+N, both channels driven) >100 W

Signal to Noise Ratio

>84 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)

Clipping power

>86 W (at 1 kHz 8 ohms 0.1 % THD) >102 W (at 1 kHz 4 ohms 0.1 % THD)

IHF dynamic power

8 ohms: 100 W 4 ohms: 125 W

Damping factor

>90 (ref. 8 ohms, 20Hz to 20kHz)

Frequency response

±0.18 dB (20 Hz - 20 kHz)

Tone controls

Treble: ±6.0 dB at 20 kHz Bass: ±6.0dB at 60 Hz

Channel separation

>93 dB (1 kHz) >72 dB (10 kHz)

Input sensitivity (for 80 W in 8 ohms)

Line In: 550 mV Digital In: -12 %FS

Trigger Out

12 ± 1 V, 9 mA

Standby power

>0.5W

Maximum output level

4.0 Vrms (ref 0.0032% THD+N 100 Hz)

Signal to Noise ratio

>106 dB (20 Hz-20 kHz, ref 1V out)

THD+N

>0.006 % (20 Hz-200 Hz, ref 1.964V)

Output impedance

600 ohms

Supported audio file format

https://support.bluos.net/hc/en-us/articles/360000191327-What-Formats-are-Supported-by-BluOS

Sampling rate

up to 32 bit/192 kHz PCM

Bit depths

Bit depths 16 - 24

Network connectivity

Gigabit Ethernet RJ45

USB

1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals

Bluetooth quality

aptX HD

Bluetooth connectivity

Two-Way (Receive and Headphone modes)

Supported operating system*

Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions

Mobile Application

Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops

Front panel

Combination of front panel control knob and buttons

Gross dimensions

218 x 96 x 266 mm 8 5/8 x 3 13/16 x 10 1/2 inches

Net Weight

4.8 kg (10.6 lbs.)

Shipping weight

5.3 kg (11.7 lbs)
