NAD C 399 DAC

產品規格

Continuous output power into 8 ohms and 4 ohms

>180W (ref. 20 Hz-20 kHz at rated THD, both channels driven)

Signal/Noise Ratio

>95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)

Clipping power

210W (at 1 kHz 0.1 % THD)

IHF dynamic power

8 ohms: 217 W

Peak output current

>26 A (in 1 ohm, 1 ms)

Damping factor

>150 (ref. 8 ohms, 20Hz to 6.5kHz)

Frequency Response

±0.3 dB (20 Hz - 20 kHz)

Channel Separation

>90dB (1 kHz)

Input sensitivity (for 180 W in 8 ohms)

Line In: 201 mV

Input Impedance (R and C)

56 kohms + 100 pF

Maximum Input Signal

>4.6 Vrms (ref. 0.1 % THD)

Output Impedance

Source Z + 320 ohms

Input Sensitivity

65mV (ref. 500 mV out, Volume maximum)

Maximum voltage output IHF load

>>5 V (ref. 0.1 % THD)

Signal to Noise Ratio

>84dB (200 ohms source; A-weighted, ref. 500 mV out)

Frequency Response*

±0.3 dB (20 Hz - 20 kHz)

Maximum Input Signal at 1kHz

>80 mVrms (ref. 0.1 % THD)

Supports bit rate/sample rate

up to 24 bit/192 kHz

Frequency band

2.402G- 2.480G

Maximum transmit power (dBm)

7 dBm ± 2 dBm

Gross dimensions (W x H x D) **

435 x 120 x 390mm

Net Weight

11.2kg (24.7lb)

Shipping Weight

13.6kg (30lb)
