NAD C 379 DAC

產品規格

Signal to Noise Ratio

>106dB (IHF; A-weighted, ref. 500 mV out, unity gain)

Channel separation

>100dB (1 kHz); >90 dB (10 kHz)

Input Impedance (R and C)

56.2 kohms + 100 pF

Maximum input signal

>4.6 Vrms (ref. 0.1 % THD)

Output impedance

Source Z + 320 ohms

Input sensitivity

257 mV (ref. 500 mV out, Volume maximum)

Frequency response

±0.3 dB (20 Hz - 20 kHz)

Maximum voltage output IHF load

>4.5 V (ref. 0.1 % THD)

Maximum input signal at 1kHz

>80 mVrms (ref. 0.1 % THD)

Continuous output power into 8 ohms

80W (ref. 20 Hz-20 kHz at rated THD, both channels driven)

Continuous output power into 8 Ohms (Bridge mode)

>300W

Clipping power

>110W (at 1 kHz 0.1 % THD)

IHF dynamic power

8 ohms: 140W

Peak output current

>20A (in 1 ohm, 1ms)

Damping factor

>300 (ref. 8 ohms, 20Hz to 6.5kHz)

Input sensitivity (for 80 W in 8 ohms)

Line In: 440 mV

Supports bit rate/sample rate

up to 24 bit/192 kHz

Frequency band

2.402G- 2.480G

Standby power

>0.5W

Network standby power

>2W

Gross dimensions (W x H x D)**

435 x 100 x 410mm (17 1/4 x 4 x 16 3/16 inches)

Net Weight

9.04 kg

Shipping weight

10.88 kg
