NAD C 326BEE 綜合擴大機

產品規格

50W x 2 Continuous Power into 4 Ohms and 8 Ohms

100W, 150W, 200W IHF Dynamic power into 8, 4 and 2 Ohms, respectively

PowerDriveTM circuit

NAD SR 8 Full System Remote control

Headphone socket

Front panel Media Player (MP) input for attaching portable MP3 Player

Relay Input Switching

Holmgren Toroidal Power transformer

7 Line inputs, including two tape in/outs

All discrete circuitry

Short signal path from input to output

All sockets Gold plated

Tone controls defeat switch

Main-amp input & pre-amp outputs

Subwoofer (mono) Out

Soft ClippingTM

IR Input/Output

12 volt trigger out

THD (2V in 2V out, CCIF IMD, DIM 100)

>0.004% (ref. 20Hz - 20kHz)

Signal/Noise ratio IHF

>100dB (A-weighted, ref. 500mV)

1kHz

>80dB

10kHz

>70dB

Input impedance (R and C)

100 kilohm+ 320pF

Maximum input signal

>8Vrms (ref. 0.1 THD)

Pre out

75 Ohm

Tape out

Source Z + 1 kilohm

Input sensitivity

159mV (ref. 500mV out)

Frequency response

±0.1dB (ref. 20Hz - 20kHz, Tone defeat ON)

IHF load

>10V (ref. 0.03% THD)

600 Ohm load

>10V (ref. 0.03% THD)

Treble

±5dB at 10kHz

Bass

±8dB at 100Hz

Continuous output power into 8Ω and 4Ω (Stereo)

>50W (ref. rated THD, 20Hz-20kHz, both channels driven)

Clipping power

>65W (ref. 1kHz 1% THD)

8 Ohm

100W

4 Ohm

150W

2 Ohm

200W

Peak output current

>20A (ref. 1 Ohm, 1ms)

Signal/Noise ratio

>100dB (A-weighted, ref. 1W)

Damping factor

>100 (ref. 8 Ohm, 50Hz and 1kHz)

Input impedance

20 kilohm + 1nF

Voltage gain

29dB

Headphone output impedance

68 Ohms

Channel separation 1kHz

>80dB

Output current

50mA

Output voltage

+12V

Rated power

290W (ref. 230V AC 50 Hz; 120V AC 60Hz)

Net

435 x 100 x 286mm

Gross*

435 x 116 x 332mm

Net weight

15.21lb (6.9kg)

Shipping weight

20lb (9.1kg)
