NAD C 3050 BluOS 網路串流機

產品規格

Signal to Noise Ratio

>95 dB (IHF; A-weighted, ref. 500 mV out, unity gain)

Channel separation

>100 dB (1 kHz)

Input impedance (R and C)

28 kohms + 360 pF

Maximum input signal

>4.5 Vrms (ref. 0.1 % THD)

Output impedance

440 ohms

Input sensitivity

270 mV (ref. 500 mV out, Volume maximum)

Frequency response

±0.3 dB (20 Hz - 20 kHz)

Maximum voltage output IHF load

>2 V (ref. 0.1 % THD)

Input Impedance (R and C)

46 kohms/100 pF

Maximum input signal at 1kHz

>80 mVrms (ref. 0.1 % THD)

Supported audio file format

MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS

Supported high resolution audio file format

FLAC, MQA, WAV, AIFF

Sampling rate

up to 192 kHz

Bit depths

16 - 24

Music Services

Click here

Internet Radio

Click here

Integration partners

Control4, Crestron, ELAN, Lutron, Push, Roon, RTI, URC

Voice Control

Skills and support for Amazon Alexa and Apple’s Siri with corresponding enabled devices and App

Network connectivity

Gigabit Ethernet RJ45

Supported network file share protocol

Server Message Block (SMB)

USB

1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals

Bluetooth quality

aptX HD 5.0

Bluetooth connectivity

Two-Way (Receive and Headphone modes)

Supported operating system

Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions

Mobile Application

Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops

Continuous output power into 8 ohms and 4 ohms

100W (ref. 20 Hz-20 kHz at rated THD, both channels driven)

Clipping power

>115 W (at 1 kHz 0.1 % THD)

IHF dynamic power

8 ohms: 180 W

Peak output current

>20A (in 1 ohm, 1 ms)

Input sensitivity (for 100 W in 8 ohms)

540 mV Digital: -6dBFS

Power consumption OFF mode (Power switched OFF)

0.1 W

Frequency band

2.402G- 2.480G

Gross dimensions (W x H x D) ****

450 x 127 x 355mm 17 1/4 x 5 x 14 inches

Net weight

10 kg (22 lbs)

Shipping weight

12.6 kg (27.8 lbs)
