KEF Ci200QSb-THX 崁入式喇叭

產品規格

標示阻抗

6 Ohm - Passive Mode (Crossover "ON") N/A - Active Mode (KASA500)

靈敏度

85dB - Passive Mode (Crossover "ON") N/A - Active Mode (KASA500)

Crossover Frequencies

100Hz - Passive Mode (Crossover "ON") N/A - Active Mode (KASA500)

頻率響應

40Hz-100Hz - Passive Mode (Crossover "ON") 18Hz-140Hz - Active Mode (KASA500)

驅動單體

LF: 200mm (8 in.)

Recommended Amplifier Power

10-150W - Passive Mode (Crossover "ON") KASA500 - Active Mode (KASA500)

產品外部尺寸 (H X W X D)

Diameter: 273 x 273 x 106 mm (10.75 x 10.75 x 4.17 in.)

圖樣尺寸 (H X W)

238 x 238 mm (9.37 x 9.37 in.)

安裝深度

天花板厚度(最大值) : 40mm (1.58 in.) 天花板厚度(最小值) : 6mm (0.24 in.)

表面安裝深度

101.6mm (4 in.)

選配框架

RIF200S

淨重

3.3kg (7.28 lbs)

單位

一件
