KEF Ci200ER 崁入式喇叭

產品規格

Nomimal Impedance

8 Ohms

Sensitivity

90dB (2.83V/ 1m)

Frequency Response

45Hz - 20kHz (±6dB) open-backed

Crossover Frequencies

2.8kHz

Drive Units

LF: 200mm (8in.) HF: 16mm (0.6in.)

Recommended Amplifier Power

10-125W

Product External Dimensions

Diameter : 289.6mm (11.4in.) Depth : 103.3mm (4.07in.)

Cut Out Dimensions

Diameter : 240mm (9.45in.)

安裝深度

天花板厚度(最大值) : 37mm (1.46 in.) 天花板厚度(最小值) : 6mm (0.24 in.)

Mounting Depth From Surface

97.2mm (3.83in.)

Optional Rough In Frame

RIF200R

Optional Rear Enclosure

RNC200R

Net Weight

1.6kg (3.6lbs)

Unit Measurement

Piece
